ZWCAD Interface และคำสั่งที่คุ้นเคย
ZWCAD มี Classic และ Ribbon interface ในลักษณะที่ผู้ใช้งานคุ้นเคย และสามารถเปลี่ยนรูปแบบการจัดวางคำสั่งได้ตามที่เหมาะสมกับการใช้งานของผู้ใช้งาน จากการใช้ลักษณะอินเตอร์เฟซและคำสั่ง CAD แบบที่ผู้ใช้งานรู้วิธีใช้อยู่แล้ว ทำให้ผู้ใช้งานสามารถเปลี่ยนมาใช้งาน ZWCAD ได้ทันที โดยไม่ต้องเรียนรู้การใช้งานใหม่

ใช้ไฟล์ร่วมกับซอฟต์แวร์อื่นได้
เปิด บันทึกและแชร์ ไฟล์งานเขียนแบบ DWG/DXF จากซอฟต์แวร์อื่นได้อย่างลงตัว

การใช้งานไฟล์ร่วมกัน

เปิด และ บันทึกไฟล์จาก DWG/DXF จาก ACAD

นำเข้า DGN แลกเปลี่ยนไฟล์กับ MicroStation®
Innovation

SmartVoice
บันทึกเสียงอธิบายรายละเอียดลงในไฟล์

SmartMouse
ใช้คำสั่งจากคลิกขวาและลากเม้าท์เพื่อใช้คำสั่งลัด

SmartSelect
การกรองสำหรับการเลือกแบบ Multi

Smart Plot
การ Plot หลายโมเดลจากพื้นที่เขียนแบบ

Barcode & QR Code
แปลงข้อมูลตัวอักษรเป็น Barcode หรือ QR Code และฝั่งลงใน Drawing
2D Drafting

PDF Underlay Manager
จากการไฟล์ PDF Underlay สะดวกยิ่งขึ้น

Cycle Selection
ตรวจสอบและเลือกวัตถุที่ซ้อนทับกันง่ายๆ

Auto-complete Command input
ช่วยหาคำสั่งอย่างรวดเร็ว

External Reference
แนบไฟล์ DWG เพื่อเป็นข้อมูลอ้างอิง

Table
ใช้งานตารางในการนำเสนอข้อมูล

MLeaders
แนบ Multi-Leader เป็นคำอธิบายประกอบ

Associative Dimension
เส้นบอกขนาดที่เปลี่ยนตามขนาดของวัตถุ

Revision Cloud
สร้าง Revision Cloud เพื่อบอกตำแหน่งจุดที่มีการแก้ไข

Layer Properties Manager
ตั้งค่าคุณสมบัติ Layer เช่น สี ลักษณะเส้น และ VP Freeze

Layer Properties Manager
ตั้งค่าคุณสมบัติ Layer เช่น สี ลักษณะเส้น และ VP Freeze

Layer Properties Manager
ตั้งค่าคุณสมบัติ Layer เช่น สี ลักษณะเส้น และ VP Freeze
Advanced Tools

Lisp Debugger
ตรวจสอบและแก้ไขโคดที่มีบคเพื่อให้โปรแกรม Lisp ถูกต้องทั้งหมด

Data Extraction
ถอดและบันทึกข้อมูลของวัตถุเป็นตารางไฟล์แบบ .csv /.xls

Annotative Object
สร้างเส้นบอกขนาดในจุดที่แตกต่างกันเพื่อให้อ่านสะดวก

Match Property
ใช้รูปแบบที่มีอยู่ในวัตถุอื่น

Insert OLE object
ฝังวัตถุ OLE ในงานออกแบบ

File Compare
ค้นหาจุดที่แตกต่างระหว่างงานออกแบบ

Tool Palettes
การจัดการ แชร์ และวางคำสั่ง Blocks และเครื่องมืออื่นๆ

Super Hatch
ใช้ Block ไฟล์ drawing หรือ ภาพในการเป็นแพทเทิร์น hatch

Reference Manager
จัดการไฟล์ภายนอก เช่น ข้อความ ภาพ และงานออกแบบ

Object Isolation
ควบคุมการแสดงผลแบบเจาะจงวัตถุ

Quick Calculator
การจัดการคำนวณ CAD

Block Attribute Manager
มุมมอง แก้ไข และซิงค์กับแอตทริบิวต์

Design Center
ค้นหาและใช้งานที่เคยออกแบบไว้อย่างรวดเร็ว

PDF และ DWFx underlays
แนบไฟล์ PDF และ DWFx ลักษณะ Underlays
3D Features

Modeling
สร้างและแก้ไขโมเดล 3 มิติ

Viewing
มุมมองภาพ 3 มิติ อย่างอิสระ และภาพเสมือนจริง DVIEW


Visualizing
ซ่อนเงา และ Render
Output

พิมพ์ STB/CTB รูปแบบการ Plot
กำหนดวิธีพิมพ์ต่างๆ เช่น สี ความละเอียด เส้น

พิมพ์หรือบันทึกในฟอร์แมทอื่น
ส่งออก DWG เพื่อรูปแบบอื่นๆ เพื่อใช้ร่วมกัน
